Product Overview
The GH719 is a 10.525GHz microwave radar sensor module designed for IoT devices, capable of non-contact moving object detection through non-metallic enclosures. Supporting 16-level sensitivity adjustment, 4 trigger logics, and light control functionality, it is ideal for smart home, security monitoring, and industrial IoT applications.
Product Features
· Wide Voltage Power Supply: 3.3V-20V input, compatible with various IoT controllers and battery systems
· Ultra-Low Power Consumption: Standby current as low as 1.6mA, supporting long-term standby for battery-powered devices
· Through-Mount Installation: Penetrates plastic, glass, and wooden enclosures while maintaining device integrity
· Environmental Stability: Resistant to RF interference, unaffected by temperature, humidity, airflow, or light conditions
· Flexible configuration: 16-level sensitivity (1-12 meters) + 4 trigger modes to adapt to different scenarios
· Digital output: TTL level signal, directly connected to MCU GPIO, no ADC conversion required
%%
· Light control function: Supports external photoresistor for automatic day/night mode switching
%%
· Dual models available: GH719 (industrial grade) and GH719C (consumer grade) in two sizes
· Light control function: Supports external photoresistor for automatic day/night mode switching
· Dual models available: GH719 (industrial grade) and GH719C (consumer grade) in two sizes
